1040×550mm Table · 350×450mm X/Y Travel · 500kg Max Load
The DD703 is a high-precision 3-axis CNC EDM drilling machine engineered for deep-hole micro-drilling in conductive materials. It’s ideal for producing fast, accurate wire-cut EDM starter holes or cooling channels in high-hardness molds and dies. With a large 1040×550mm worktable and a 350×450mm X/Y axis travel, it supports medium to large-scale parts up to 500kg.
3-axis CNC EDM Drilling Machine DD703
Spare parts supply
On-site installation service
Customized design
Why Choose Our CNC Solutions
Key Features
- ● CNC-controlled X/Y/Z axes for full automatic deep-hole positioning and programming.
- ● Touchscreen CAD-based control system simplifies layout and array drilling tasks.
- ● Precision spindle supports high-speed drilling with φ0.3–φ3mm electrodes.
- ● Rigid cast structure and 500kg table load capacity ensure vibration-free performance.
- ● Ideal for hardened steels, carbides, copper alloys, and graphite block drilling.
Get More Details →
Recommended Configurations
- ● Electrode chuck set: Holds multiple diameters securely from φ0.3 to φ3mm.
- ● High-pressure flushing unit: Removes chips and improves deep-hole quality.
- ● Automatic Z-axis depth limiter: Prevents over-drilling and ensures accuracy.
- ● Oil mist separator: Keeps working environment clean during extended use.
- ● Integrated hole pattern software: Supports grid, arc, angle, and custom patterns.
- ● Remote monitoring module: Enables real-time tracking of drilling progress and diagnostics.
Get More Details →
Application Case
- ● Client: Mold Manufacturing Plant – Malaysia.
- ● Use Case: Starter hole drilling on hardened tool steel mold bases for follow-up wire EDM.
- ● Setup: DD703 with φ0.8mm brass tube electrode, high-pressure flushing, 3D hole layout import.
- ● Results: Hole roundness deviation: < 0.015 mm ,Depth consistency: ≤ ±0.02 mm across 120 holes,Electrode life: 500+ holes per rod on average ,Client feedback: “The DD703 dramatically improved our hole precision and batch consistency—it’s now the core of our EDM prep line.”
Get More Details →
Product Specifications
0
Catalog
Frequently Asked Questions
Minnuo’s EDM drilling machines are perfect for hard materials and components like aerospace turbine blades, mold cooling holes, nozzles, ejector pins, and fuel injectors, requiring fine and deep hole drilling.
EDM drilling can process hardened steel, stainless steel, titanium, carbide, copper, aluminum, and nickel-based alloys, regardless of material hardness.
Minnuo’s EDM drills can produce holes from Ø0.3 mm to Ø6.0 mm, with depth-to-diameter ratios exceeding 300:1, achieving high aspect ratio deep holes efficiently.
Absolutely! Just send us the hole diameter, depth, material, and production volume, and Minnuo’s engineers will recommend the most suitable EDM drilling machine model within 10 minutes.
Yes! We offer customizations for maximum machining depth, machine table size, dielectric system configuration, automatic electrode changers (AEC), and CNC or manual control systems.
Minnuo EDM drills use servo-controlled feed systems, high-frequency pulse power supplies, real-time monitoring systems, and undergo sample testing and calibration before delivery.
Standard models can be delivered within 20–30 working days. Customized or special configurations usually require 30–45 working days.
Minnuo provides a one-year warranty, 24/7 technical support, free online training, remote troubleshooting, and lifetime spare parts service.
