X-Axis Travel: 2600 mm · Y-Axis Travel: 1900 mm · Z-Axis Travel: 900 mm
The XH2519 Moving Table Gantry Machining Center is engineered to tackle demanding machining tasks, offering superior rigidity and a large working envelope. With its precise motion control and high-speed capabilities, it excels in heavy-duty machining of complex parts across various industries.
XH2014/XH6022
Spare parts supply
On-site installation service
Customized design
Why Choose Our CNC Solutions
Key Features
- ● Generous Work Area With 2600 mm of X-axis travel and 1900 mm of Y-axis travel, this machining center is ideal for large workpieces and complex geometries.
- ● High-Speed Spindle Operating at 6000 rpm, the spindle enables quick material removal and ensures a consistent finish quality for a variety of applications.
- ● Sturdy Gantry Design The robust gantry design minimizes vibration and ensures stable machining, even during extended operations.
- ● Optimized Chip Management The efficient chip removal system maintains a clean working environment, reducing downtime and extending tool life.
- ● Versatile Machining Range Capable of handling both simple and intricate machining tasks, this machine delivers exceptional accuracy and precision across a wide range of materials.
Get More Details →
Recommended Configurations
- ● Spindle: High-precision spindle (SKF, NSK), high-speed spindle, air-cooled/water-cooled spindle
- ● CNC Control System: High-performance CNC systems (FANUC, Siemens, GSK, KND, SYNTEC, Mitsubishi, etc.)
- ● Fixtures: Magnetic chuck, V-type fixture, fixed worktable fixture
- ● Drive System: Servo motor drive, linear motor drive, dual-drive system
- ● Tool System: 40-tool chain-type tool magazine, Taiwan-made 24-tool magazine, automatic head changing system
- ● Cooling System: High-pressure cooling system, built-in cooling system, mist cooling system, automatic cutting fluid supply system
- ● Other Configurations: Screw chip conveyor, magnetic hinged belt chip conveyor, gantry loader, Renishaw OMP60 workpiece probe, Renishaw TS27R contact tool setter
Get More Details →
Application Case
- ● Client: Automotive Supplier – Germany
- ● Use Case: Machining of intricate engine components and large-scale molds
- ● Setup: XH2519 with integrated rotary table and coolant-through tool system
- ● Results: • Decreased production time by 30%, thanks to fast spindle speeds and efficient tool changes • Achieved a surface finish of Ra ≤ 1.5 μm for high-precision molds • Maintained tight tolerances of ±0.002 mm, ensuring flawless product quality
- ● Client Feedback: “The XH2519 has been a game-changer for our mold production, significantly improving both speed and precision.”
Get More Details →
Product Specifications
0
Catalog
Frequently Asked Questions
Our moving table gantry machining centers are ideal for large molds, engine blocks, aerospace panels, heavy mechanical parts, and rail transit components requiring high-precision and multi-surface machining.
Moving table gantries provide better dynamic stability, superior chip evacuation, higher precision for medium to large parts, and easier automation integration due to the independent worktable motion.
Minnuo’s moving table gantries feature fixed gantry structures, moving worktables on precision guideways, high-torque spindles, automatic tool changers (ATC), and optional multi-angle heads.
Absolutely! Minnuo’s engineers can recommend the best-fit moving table gantry machining center model within 10 minutes after reviewing your part drawings. Full production line proposals are available within 5 working days.
Yes! We offer customization for spindle type, travel dimensions (X/Y/Z), worktable size, ATC capacity, milling head types, and automation options such as pallet changers and robotic interfaces.
All machines are built with high-grade Meehanite castings, and undergo laser calibration, dynamic balance testing, and geometric accuracy inspection to guarantee superior precision and reliability.
Standard models are delivered within 40–60 working days. Customized models or special configurations may require 60–90 working days, depending on complexity.
Minnuo offers a one-year warranty, 24/7 technical support, remote troubleshooting, on-site service, and spare parts supply guaranteed for 10+ years.
